C4MV015065T

650 V, 15 mΩ, TOLT (TSC) package, Industrial qualified, Discrete Silicon Carbide (SiC) MOSFET

Composite image of the front and back of a Wolfspeed Discrete Silicon Carbide Schottky diode in a TOLT package.

Parametric Data

No filters selected, showing all 1 products

Product SKU	Buy Online	Request Sample	Data Sheet	CAD Model	Status	Blocking Voltage	R_DS(ON) at 25°C	Current Rating	T_jmax	Package	Qualification
C4MV015065T New					Active	650 V	15 mΩ	150 A	175 °C	TOLT (TSC)	Industrial

Ordering & Compliance

C4MV015065T Ordering

Part Number	C4MV015065T-TR
Order Status	Active
Buy Online
Request Sample	Available
Package	TOLT (TSC) T&R
Container Type	Tape & Reel
Container Qty.	1800
Standard Packing Qty.	1800
Minimum Order Qty.	1800

C4MV015065T Compliance

Halogen Free	Yes
RoHS Declaration	Download
REACH Declaration	Download
California Prop 65	Learn More
ECCN	EAR99
Moisture Sensitivity Level	MSL 1

C4MV015065T Related Documents

Soldering & Handling	PRD-05653: Recommended Solder Profiles for Power Products (PDF)
Packing & Shipping	Power Product Packing & Shipping Reference Guide (PDF)

Product Details

Features

Industry compatible drive voltage [+15 to 18V]
Industry standard top side cooled (TSC) package
High power dissipation capability
Optimized package with separate driver source pin
High-speed switching with low capacitances
Soft body diode to minimize voltage overshoot
Halogen free, ROHS compliant

Benefits

Compatible with industry standard gate drivers
Increase power density
Reduce cooling requirements
Reduce switching losses and minimize gate ringing
Higher system efficiency
Increase system switching frequency

Typical Applications

EV chargers
Solar / Energy storage systems (ESS)
Motor control
Industrial power supplies
High voltage DC/DC converters

Featured Resources

Documents, Tools & Support

Technical & Sales Documents
Tools & Support
Compliance

Documents

28 Documents Available

Document Type	Document Name	Last Updated
Data Sheets	C4MV015065T (PDF) New	11/2025
Application Notes	PRD-09597: Introduction to Pulsed Current Safe Operating Area (PDF) New	10/2025
Application Notes	PRD-08182: Designing with Wolfspeed Top Side Cooled Packages (PDF) New	08/2025
Application Notes	PRD-09129: Mitigating Package Induced Failures (PDF)	05/2025
Application Notes	PRD-05652: Mounting Recommendations and Thermal Measurement for Wolfspeed® SiC Power Devices in Through-Hole Packages (PDF)	02/2025
Application Notes	PRD-04814: Design Options for Wolfspeed® Silicon Carbide MOSFET Gate Bias Power Supplies (PDF)	01/2025
Application Notes	PRD-08907: Mitigating EMI with SiC Solutions in Renewable Energy & Grid-Connected Power Converters (PDF)	01/2025
Application Notes	PRD-08999: Turn-Off Gate Voltage Considerations for SiC MOSFETs (PDF)	12/2024
Application Notes	PRD-08937: Impact of VGS on SiC MOSFET Characteristics (PDF)	11/2024
Application Notes	PRD-06752: PCB Layout Techniques for Discrete SiC MOSFETs (PDF)	09/2024
Application Notes	PRD-08710: Measuring Stray Inductance in Power Electronics Systems (PDF)	07/2024
Application Notes	PRD-08734: Understanding and Simulating Parasitic Inductance in Silicon Carbide Systems (PDF)	07/2024
Application Notes	PRD-08367: EV Charging Power Topologies Design Guidebook (PDF)	01/2024
Application Notes	PRD-03043: Measuring Switching and Conduction Losses in LTspice® Simulation Software (PDF)	01/2024
Application Notes	PRD-08376: Thermal Characterization Methods and Applications (PDF)	01/2024
Application Notes	PRD-08296: SiC MOSFET Short Circuit Events (PDF)	11/2023
Application Notes	PRD-06379: Environmental Considerations for Power Electronics Systems (PDF)	08/2023
Application Notes	PRD-06933: Capacitance Ratio and Parasitic Turn-on (PDF)	01/2023
Application Notes	PRD-05653: Recommended Solder Profiles for Power Products (PDF)	09/2022
Application Notes	PRD-05641: Designing with Silicon Carbide in Energy Storage Applications (PDF)	02/2022
Application Notes	Selection Guide of SiC Schottky Diode in CCM PFC Applications (PDF)	09/2015
Test Report	PRD-02344: SiC MOSFET Short-Circuit Protection Using Skyworks™ Si828x Gate Driver (PDF)	03/2022
White Papers	Designed to Last, Even in the Harshest Environments (PDF) New	11/2025
White Papers	Enhancing System Durability with Advanced Packaging for Silicon Carbide (PDF)	11/2025
White Papers	SiC Power Module Reliability: Wolfspeed’s Power Cycling and Lifetime Modeling Approach (PDF) New	11/2025
Product Catalog	Power Product Line Card (PDF)	01/2025
Sales Terms	Wolfspeed, Inc. Sales Terms and Conditions (PDF)	04/2025
Packing & Shipping	Power Product Packing & Shipping Reference Guide (PDF) This document details the production packaging details including container type, quantity, MOQ, and dimensions as well as the moisture sensitivity level (MSL) for discrete SiC Schottky Diodes and MOSFETs.	11/2025
